BASCO Industrial PC
NK720 Rackmount Industrial PC | Modular & Expandable
In stock
Price Match
Multibuy Discounts
Pay with
Your transaction is protected with advanced security measures to keep your information confidential
About NK720 Rackmount Industrial PC | Modular & Expandable
The BASCO 2U Rackmount Industrial PC is a high-performance, modular industrial computing platform designed for automation, control, networking, and other demanding industrial applications. Powered by 12th, 13th, or 14th Gen Intel® Core™ processors and supporting up to 64GB DDR4 memory, it delivers reliable computing performance with extensive expansion capabilities. Unlike systems with fixed I/O configurations, its flexible PCI/PCIe expansion architecture and configurable industrial interfaces allow customers to tailor the system to specific project requirements, including additional LAN, GPIO, COM, CAN Bus, and other industrial I/O interfaces. This modular design helps reduce customization limitations while providing a scalable and cost-effective solution for long-term industrial deployment.
NK720 Rackmount Industrial PC | Modular & Expandable
| Category | Item / Interface | Specification | Notes / Physical Spec |
|---|---|---|---|
| CPU | Supported Processors | Alder Lake 12th Gen: i3-12300, i5-12400, i7-12700, i9-12900 Raptor Lake 13th Gen: i3-13100, i5-13400, i7-13700, i9-13900 Raptor Lake 14th Gen: i3-14100, i5-14400, i7-14700, i9-14900 |
— |
| Chipset | Chipset | Intel H670 | — |
| Power | 1× 24-pin ATXPWR1 | Standard ATX power connector | — |
| 1× 8-pin ATX2 | Max CPU Turbo TDP ~219W; recommended PSU ≥500W | — | |
| Memory | 2× DIMM Slots | PC-DDR4, 2133/2400/2666/2933/3200 MHz; max 64GB | — |
| Networking | 6× LAN Ports | Default: 1× Intel I219W + 5× Intel I226-V GbE; supports WoL, PXE | — |
| 1× M.2-WiFi | PCIe 3.0; Key-E, 2230 form factor; supports WiFi/BT module | — | |
| Graphics | Integrated GPU | Intel UHD Graphics 730/770; supports single, clone (2/3/4 displays), and extended (2/3/4 displays) modes | — |
| 1× HDMI 2.0 Port | Up to 4K @ 60Hz (4096×2160 / 3840×2160) | — | |
| 1× HDMI Header | Up to 4K @ 60Hz | 16-pin (2×8), 2.0mm pitch | |
| 1× VGA Port | Up to 1920×1080 @ 60Hz | — | |
| 1× eDP Header | Up to 4K @ 60Hz | 30-pin (2×15), 2.0mm pitch | |
| 1× eDP PWR Header | eDP voltage control | 6-pin (2×3), 2.0mm pitch | |
| eDP Cable | 30-pin backlight-integrated cable | — | |
| 2× PCIe x16 Slots | PCIe 4.0; x8 electrical; supports discrete GPU | — | |
| 3× PCIe x4 Slots | PCIe 4.0; supports discrete GPU | — | |
| Display Priority | Default: dGPU disables onboard display outputs; BIOS configurable for simultaneous output | — | |
| 8× USB 3.2 Gen1 Ports | Rear I/O; up to 5Gbps | — | |
| USB | 1× F_USB3_A Header | Front USB 3.2 Gen1; 2 ports per header | 20-pin (2×10), 2.0mm pitch |
| 1× F_USB1 Header | Front USB 2.0; 2 ports per header | 9-pin (2×5), 2.54mm pitch | |
| 1× F_USB2 Header | Front USB 2.0; 2 ports per header | 9-pin (2×5), 2.54mm pitch | |
| 1× F_USB3 Header | Front USB 2.0; 2 ports per header | 9-pin (2×5), 2.54mm pitch | |
| Audio | Audio Codec | Realtek ALC897 HD, 6-channel | — |
| 1× Line-In | Blue | — | |
| 1× Line-Out | Green | — | |
| 1× Mic-In | Red | — | |
| 1× F_AUDIO Header | Front audio header | 9-pin (2×5), 2.54mm pitch | |
| Storage | 1× M.2 (NGFF) Slot | PCIe 3.0, Key-M, 2280 (2242 optional); default NVMe (PCIe), configurable to support both NVMe & SATA | — |
| 4× SATA 3.0 Ports | SATA 1/2/3/4; SATA 3.0 | — | |
| M.2 Note | When reconfigured for NVMe + SATA coexistence, SATA2 is disabled | — | |
| 1× F_PANEL Header | Power switch, power LED, HDD LED, reset | 9-pin (2×5), 2.54mm pitch | |
| Front Panel | 1× AUTO_SW Header | Hardware power-on resume (auto power on) | 3-pin, 2.0mm pitch |
| 2× PCI Slots | Standard PCI slots | — | |
| Other I/O | 2× COM Headers (COM1/2) | RS-232 / RS-485 selectable via BIOS | 9-pin (2×5), 2.54mm pitch |
| 1× JCOM1 Header | COM3 pin 9 voltage: 0V/5V/12V selectable | 6-pin (2×3), 2.0mm pitch | |
| 1× JCOM2 Header | COM4 pin 9 voltage: 0V/5V/12V selectable | 6-pin (2×3), 2.0mm pitch | |
| 1× COM3/4/5/6 Header | Default RS-232; all COM ports configurable to TTL via hardware mod | 9-pin (2×5), 2.54mm pitch | |
| 1× FAN1 Header | CPU fan; PWM/thermal control supported | 4-pin, 2.54mm pitch | |
| 1× FAN2 Header | System fan; no thermal control | 3-pin, 2.54mm pitch | |
| 1× CLR_CMOS Header | CMOS clear / reset jumper | 3-pin, 2.0mm pitch | |
| 1× GPIO_CN Header | GPIO control header | 10-pin (2×5), 2.0mm pitch | |
| 1× JLPT Header | Parallel (LPT) port header | 25-pin (2×13), 2.0mm pitch | |
| Environment | Operating Temp. | -10° C ~ 60° C | — |
| Operating Humidity | 5% ~ 95% RH, non-condensing | — | |
| BIOS | BIOS Type | AMI BIOS; supports AC recovery, scheduled power-on, remote power control, auto device detection | — |
| Watchdog | Watchdog Timer | 256 levels, 0 - 255 sec | Programmable |
| OS Support | Supported OS | Windows 11, Windows 10, Linux, etc. | — |
Customer Reviews
Fulcrum Control Technologies
We needed several mini PCs for different automation tasks and found BASCO during our search for compact industrial systems. Their team quickly understood our requirements and made the necessary hardware adjustments without complicating the process. Communication was smooth, response time was fast, and—even with customization—the delivery timeline exceeded expectations. Pricing was reasonable compared with other industrial suppliers. For anyone looking for reliable mini PCs with flexible configuration options, BASCO is a solid choice.
Takamul Automation Group
After facing repeated production downtime due to overheating in our legacy controllers, we searched for industrial computers with strong environmental resistance. BASCO stood out with their IP67-rated units and TÜV-certified vibration compliance, which gave us confidence to deploy them in our automotive welding lines. Their systems offered a cost advantage without compromising build quality. Since installation, we’ve seen significantly more stable operation under the tough thermal and EMI conditions of our facility.
DeltaSync Industrial
We began working with BASCO after meeting their engineering team at Hannover Messe 2019. Their technical depth became clear early on: they optimized our testing cycle through remote customization, pinpointed an EMC-related alignment issue we had struggled to diagnose, and helped reduce long-term maintenance costs through a structured TCO program. Based on consistent performance and engineering support, we upgraded BASCO to our Tier-1 supplier list and extended our partnership through 2030.
Präzision Dynamics
After three years of continuous operation in our machining environment, BASCO’s rugged systems have demonstrated impressive reliability. Their engineers supported us through detailed hardware hardening and ensured smooth integration with our existing automation layer. Though custom builds took additional time, the return on investment has been clear: stable 24/7 performance, reduced unplanned downtime, and a predictable lifecycle plan that helps lower our equipment refresh costs.
Dhruva Nanotech
Integrating new industrial PCs into our legacy control infrastructure was a major challenge, but BASCO handled it professionally from the start. Their team planned a phased migration that allowed us to upgrade with zero downtime. The redundant hardware design eliminated several failure points in our old system. What we appreciate most is their proactive lifecycle support—keeping our compliance standards current and giving us clear upgrade guidance ahead of regulatory changes.
Sílício Brasil
When our fab’s legacy controllers started showing signs of instability, BASCO provided replacement units on a surprisingly tight schedule. Their IPCs were compatible with our older drivers and introduced useful improvements like real-time thermal monitoring. The custom ESD-safe configuration took additional coordination but worked flawlessly once deployed. Since installation, we haven’t experienced any unexpected outages, and firmware updates have strengthened system security without disrupting operations.
Yantrix
In our Chennai plant, seasonal heat and dust caused frequent shutdowns in our previous computers. BASCO’s heat-resilient motherboards and IP-rated enclosures significantly reduced these incidents. Their local engineering support was particularly valuable—they understood India’s grid fluctuations and delivered surge-hardened systems that other vendors couldn’t provide. Since implementation, emergency repair calls have dropped noticeably, and overall equipment lifespan has improved.
AmandlaGrid
In our African operations, high ambient temperatures and unstable power grids often push control systems to their limits. BASCO supplied temperature-resilient motherboards and IP66 dust-proof IPCs that performed reliably even under 48°C conditions. Their engineers also helped stabilize our power input with supercapacitor-based solutions. While customization extended lead times slightly, the improvements in system lifespan and reduction in failures have been substantial.
Технопром Автоматика
Our Siberian plant requires equipment that can start and operate in extremely low temperatures. BASCO’s cold-resistant industrial PCs performed reliably where several competitor units had failed. Their protective coatings also helped reduce corrosion issues caused by smelting fumes. After deployment, we recorded fewer temperature-related failures and smoother integration with our older PLC systems. For operations in harsh winter climates, BASCO has proven to be a dependable partner.
