BASCO Industrial PC
Industrial All in One Panel PC BASCO IPPC-25D3-4L6C-17S 4 LAN 6 COM
$0.00 USD
Price Match
We check our prices every day to ensure we can bring you the best price possible. In the unlikely case that you have found a cheaper price then please contact us by (+86) 189 3816 7175 and we'll do our best to answer your query right away!
Multibuy Discounts
Planning to implement a systematic industrial control project? We offer customized project solutions and discounts. Please call us at (+86) 189 3816 7175 for more details and your tailored quote.
Pay with
Your transaction is protected with advanced security measures to keep your information confidential
$0.00 USD
$0.00 USD
About Industrial All in One Panel PC BASCO IPPC-25D3-4L6C-17S 4 LAN 6 COM
BASCO IPPC-25D4-4L6C-17S Technical Parameters
the table display is not optimized for mobile devices. Please contact online customer service to obtain the data sheet.
Industrial Panel PC Specification
| CD Display | Touchscreen | |||||||
|---|---|---|---|---|---|---|---|---|
| Display Type | 17″ TFT LCD (LED backlight) | Touchscreen Type | 5-Wire Resistive | Projected Capacitive | Non-Touchscreen | |||
| Resolution | 1280*1024 | Touchscreen Method | Single point | Ten point | – | |||
| Luminance | 250 cd/m2 (Typ.) | Surface | 3H | 6H | 6H | |||
| Viewing Angle | 85/85/80/80 (Typ.)(CR>=10) | Durability | 1 million touches | – | – | |||
| Contrast Ratio | 1000 : 1 (Typ.) ( Transmission ) | Transparency | 75%±8% | 85±3% | >88% | |||
| System | ||||||||
| CPU | Model | Intel® Core™ I5-4300U, Dual-core, 1.90 GHz | Intel® Core™ I7-4600U, Dual-core, 2.10 GHz | |||||
| RAM | SO-DIMM | 1* SO-DIMM Socket, DDR3L-1333/1600 MHz, Up to 8GB | ||||||
| Storage | MSATA | 1* mSATA3.0 slot on board (6Gb/s) | ||||||
| Supported OS | Windows & Linux | Win 7, Win 8, Win 10, Win11, Linux (Ubuntu, Dibian, Kali, CentOS, etc.); WES 7; Win 10 IoT | ||||||
| I/O INTERFACE | COM | 1* RS232/422/485 header (COM2); 1* RS232/485 header (COM3); 4* RS232 header (COM1/4/5/6); | ||||||
| Ethernet | 4* Intel® i211 GbE LAN, support network wake-up/PXE function | |||||||
| USB | 2* USB2.0; 2* USB3.0; 2* USB 2.0 header | |||||||
| Video | 1* HDMI, support 3280×2000@60Hz; 1* VGA, support 1920×1200@60Hz; | 1* HDMI, support 3200×2000@60Hz; 1* VGA, support 1920×1200@60Hz; | ||||||
| Audio | 1* Line out; With 5.1 channels HD Audio Codec Realtek ALC662 | 1* Line out; With 5.1 channels HD Audio Codec Realtek ALC662 | ||||||
| SIM | 1* Built-in SIM card slot connected to Mini-PCIe | |||||||
| Power Supply | 12V DC; 1* DC Jack (5.5* 2.5mm); Optional 9-30V DC PWR module with Terminal Block (2-Pin, 5.08mm) | |||||||
| Other | 1* Terminal Block (4-Pin, 3.81mm) with Remote Switch and Power Indicator 1* 8-bit GPIO header with 4 inputs and 4 outputs, Input voltage range: 0-5V; | |||||||
| Extended Capabilities | Additional Internal Interface | 1* Full Size Mini-PCIe with SIM card slot (PCIe+USB2.0, support Wi-Fi+BT/ 4G) | ||||||
| Environment | Operating Temperature | Non-Touch: 0~50°C; Capacitive: -20~60°C; (w/ 0.7m/s Airflow) | ||||||
| Storage Temperature | Non-Touch: 0 ~ 50°C; Capacitive: -20 ~ 60°C | |||||||
| Relative Humidity | 40 °C @ 95%, Non-Condensing | |||||||
| Physical Characteristics | Dimensions | 388*318*57 mm | ||||||
| Net Weight | Around 4.5kg (The final weight is subject to actual ordering configuration) | |||||||
| Regulation | EMC | CE/FCC Class B, CCC | ||||||
| Safety | CE-LVD, RoHS, CCC | |||||||
Optional Processor
| CPU | Code Name | Total Cores | Total Threads | Max Turbo Frequency | Base Frequency | Cache | TDP | Memory Types | Integrated Graphics |
| Intel® Core™ I5-4300U | Haswell | 2 | 4 | 2.90 GHz | 1.90 GHz | 3 MB Intel® Smart Cache | 15W | DDR3 | Intel® HD Graphics 4400 |
| Intel® Core™ I7-4600U | Haswell | 2 | 4 | 3.30 GHz | 2.10 GHz | 4 MB Intel® Smart Cache | 15W | DDR3 | Intel® HD Graphics 4400 |
Optional Accessories
| Optional Items | Max Qty | Description |
|---|---|---|
| DC9-30V TO DC-12V PWR module | 1 | PCB, Power supply voltage conversion module, connected by header |
| Isolated 8-bit GPIO, 9-26V | 1 | Phoenix Terminal connector, connected by jumper |
| Isolated RS-232 | 6 | DB9 or Phoenix Terminal connector, connected by header |
| Isolated 8-bit GPIO, 9-24V | 1 | Phoenix Terminal connector, connected by header |
| 4G Module | 1 | Connected by M.2 interface |
| 5G Module | 1 | Connected by M.2 interface |
| WiFi Module without AP mode | 1 | Connected by M.2 interface |
Drawings and Dimensions
